F-618 Series High Speed Mini

تصنيف: Fixed Type

SUNRISE PACIFIC CO., LTD

بلد: Taiwan

هاتف: 886-3-3850780 (803)

فاكس: 886-3-3850775

الشخص الذي يمكن الاتصال به: Mr. Wu Shih-Tse

الاستفسار الآن

APPLICATIONS

Logisitcs, Courier, Food Packaging, Electronic Product, Home Applicance, Other Daily Necessity Packaging Boxes

Computer Interface Control System

Centralized control system, ensuring synchronized operation and status updates for each unit.
Intelligent Graphical User Interface

Operator can efficiently access information and navigate seamlessly, with the flexibility to switch between various box-type production modules.
Ordering Set-Up Function

Adopting simple graphical user interface, the system automatically interprets the relevant functional parameters of each unit, eliminating the necessity for manual repetitive adjustments.

The Sun Automation feeding system, capable of adapting to various conditions of corrugated sheet.
Sunrise's vacuum system enhances the flexibility tolerance of corrugated sheets, minimizing feeding challenges resulting from variations in inconsistent cardboard quality, such as titling or shifting issues.
Suitable for cardboard sheets with a thickness range of 1.5~9mm (AB-E flute), it accommodates to a variety of production requirements, including different thicknesses of cardboard sheets feeding.
Connect to the computer system for preconfiguring corrugated sheet types and dimensions, allowing for automatic adjustments in sheet feeding distance, gap between feed rolls and stopper positions.
Maximize stroke extensions automatically adjusted feeding mechanism to minimize damage to the cardboard sheets.

工-Beam Steel Structure

Minimize operational vibrations.

Ensure stability throughout the feeding process.

Improve the precision of the feeding mechanism.
Automatic Cardboard Sheet Feeding with Double-Sided Squaring

The front stop and side guide lateral movement utilize mechanisms such as linear guides and ball screws, ensuring a stable and precision in cardboard feeding.
Lead Edge Feeding with Adjustable Vacuum System

Sun Automation lead edge feeding system, in conjunction with Sunrise's designed vacuum system, enhances adaptability to varying qualities of cardboard sheets.

The “RETURN” function with automatic restoration for precise print positioning, enhances machine efficiency and significantly reduces waste production.
The vacuum transfer device minimizes displacement of print dots, allowing for adjustable gaps between the cardboard sheet and printing plate to achieve the state of “kiss-touch.” This ensures high print quality for both print dots and full-page printing.
Doctor blade chamber inking device delivers a consistent ink volume during both high and low-speed rotations, guaranteeing clarity in print dots, fine text and even full-page printing.
Chamber blade inking device offers easy maintenance, minimal ink consumption, short cleaning time and high system stability.
Utilizing doctor chamber blade device effortlessly keeps the anilox clean and its surface moist, prolonging the lifespan of the anilox.

Rubber Wiper Inking System

Simple structure, easy to maintain.

Cost-effective ink supply system.
Chambered Doctor Blade Ink Distributing System (Optional)

Chambered doctor blade system ensures stable print quality and ink consistency in high and low-speed operations. The optional quick-change blade system allows replacement in under one minute.
Quick-lock Printing Plate Feature (Optional)

Quick printing plate replacement system allows for tool-free disassembly and installation of plates, effectively reducing order changeover time.

One Press "RETURN" Feature

Following a required pause or shutdown, simply press “RETURN” to resume production without the need for additional adjustments.
Automatic Ink Shortage Detection System

To protect the anilox roll from damage caused by insufficient ink, the system will activate an alarm notification upon detecting an ink shortage.
Auto Ink Washing System

User-friendly interface equipped with a one-press automated quick ink washing system to simplify the procedural workflow.

The ball screw mechanism facilitates the lateral movement of the cylindrical shaft and linkage plates.
Independenet slotting knife and creaser units design allowing for rapid, accurate, and high-speed control operations.
The multi-axis slotting design, incorporating additional cardboard support shaft mechanism, improves stability and precision in cardboard transportation.
Upon entering cardboard box dimensions needed, the machine automatically interprets slotting knife movement positions, simplifying operations and meeting production requirements.
Achieving pre-creasing forced strengthened and enhanced creasing strength.

Durable Slotting Mechanism

Durable slotting mechanism design, the slotting knife holder lateral movement by the linear guideway and ball screw to ensure a smooth move to make the slotting and creasing more flexible and precise.
Slotting Unit Mechanism

The independent pre-creaser, creaser, front and rear slot knives, along with cardboard support shafts enhance stability during transport and improve the efficiency of slotting and creasing processes.
Cut-off Slitting Knife

The cut-off edge-trimming knife prevents the accumulation of scraps and dust, ensuring precise slotting accuracy.
