تصنيف: منتجات
بلد: تايوان
هاتف: 886-6-2330519
فاكس: 886-6-2330398
الشخص الذي يمكن الاتصال به: Joseph Lung
نموذج | حجم الدولية | حجم طلقة النظرية | قوة لقط | الفضاء بين أشرطة التعادل | قالب فتح السكتة الدماغية |
SW-90B | 900H-326 | 226 | 90 | 360x360 | 330 |
SW-120B | 1200H-435 | 318 | 120 | 395x395 | 380 |
SW-150B | 1500H-614 | 452 | 150 | 425x425 | 430 |
SW-190B | 1900H-760 | 594 | 190 | 470x470 | 480 |
SW-230B | 2300H-958 | 763 | 230 | 515x515 | 525 |
SW-270B | 2700H-1423 | 995 | 270 | 555x555 | 570 |
SW-320B | 3200H-1703 | 1232 | 320 | 620x620 | 620 |
SW-370B | 3700H-2045 | 1502 | 370 | 700x650 | 670 |
SW-470B | 4700H-2862 | 1910 | 470 | 770x742 | 770 |
SW-570B | 5700H-4462 | 2767 | 570 | 860x800 | 860 |
الميزات القياسية لوحدة الإغلاق
- يتم نترت قضبان الربط لتقديم صلابة عالية ومقاومة تآكل أفضل.
- تهدف آلية التبديل العمودي المكونة من 5 نقاط إلى تحقيق فتح / إغلاق سريع للقالب ، وشوط أطول لقط ، وتثبيت حركة آلية التثبيت.
- يعمل التصميم الهيدروليكي القياسي للتثبيت السريع على تقصير وقت دورة الجفاف وتوفير الطاقة.
- وظيفة الضغط المنخفض هي ضمان حماية جيدة لسطح التلامس للقالب.
- يحسب محول الطاقة الخطي بدقة شوط التثبيت للحصول على دقة موضع عالية.
- تعمل الدائرة الهيدروليكية المتكاملة على تقليل درجة حرارة الزيت وفقدان الكفاءة.
STANDARD FEATURES OF INJECTION UNIT
- The double injection cylinder design gives a shorter machine length and avoids that the design of the double carriage cylinder may produce material leakage owing to high speed or high pressure.
- It includes multi-stage injection parameters like speed, pressure, or position for different kinds of molding conditions.
- The set of screws and barrels has been nitrified to strengthen the wear resistance.
- A linear transducer calculates the injection and plasticizing strokes to ensure a high positional control.
- Screw cold-start protection.
- PID temperature simulation.
- Anticorrosive bimetallic screw and barrel set (optional accessory).
